Asus ROG STRIX B850-F Gaming WIFI AM5 ATX Motherboard (ROG STRIX B850-F GAMING WIFI)
| Model | ROG STRIX B850-F GAMING WIFI |
|---|---|
| CPU | AMD Socket AM5 for AMD Ryzen™ 9000, 8000 & 7000 Series Desktop Processors* * Refer to https://www.asus.com/support/download-center/ for CPU support list. |
| Chipset | AMD B850 Chipset |
| Memory | 4 x DIMM slots, max. 256 GB, DDR5 Supports up to 8000+ MT/s (OC) with Ryzen™ 9000/8000/7000 ECC & Non‑ECC, Un‑buffered DIMM Dual‑channel architecture Supports AMD EXPO™ and ASUS AEMP |
| Graphics | 1 x DisplayPort* 1 x HDMI™ (HDMI 2.1) ** * Supports max. 8K@30 Hz (DP 1.4) ** Supports 4K@60 Hz (HDMI 2.1) |
| Expansion Slots |
AMD Ryzen™ 9000 & 7000 Series 1 x PCIe 5.0 x16 (Q‑Release Slim) AMD Ryzen™ 8000 Series 1 x PCIe 5.0 x16 (supports PCIe 4.0 x8 or x4)* AMD B850 Chipset 1 x PCIe 4.0 x16 (supports x4 mode)** * Varies by CPU type ** Shares bandwidth with M.2_3 |
| Storage |
Total: 4 x M.2 slots, 2 x SATA 6 Gb/s AMD Ryzen™ 7000 & 9000 Series M.2_1 (2242/2260/2280, PCIe 5.0 x4) M.2_2 (2280/22110, PCIe 5.0 x4) AMD Ryzen™ 8000 Series M.2_1 (2242/2260/2280, PCIe 4.0 x4) M.2_2 (2280/22110, PCIe 4.0 x4/x2)* AMD B850 Chipset M.2_3 (2280, PCIe 4.0 x4)** M.2_4 (2280, PCIe 4.0 x4) 2 x SATA 6 Gb/s ports * Varies by CPU type ** M.2_3 shares bandwidth with PCIEX16(G4) RAIDXpert2 Ryzen 9000: RAID 0/1/5/10 Ryzen 8000: RAID 0/1 Ryzen 7000: RAID 0/1/10 |
| Ethernet | 1 x Intel® 2.5 Gb Ethernet ASUS LANGuard |
| Wireless & Bluetooth | Wi‑Fi 7* (2×2, 2.4/5/6 GHz, 160 MHz, up to 2.9 Gbps) Bluetooth v5.4*** * Requires OS support (Windows 11 24H2+ for full Wi‑Fi 7) ** 6 GHz band regulatory varies by country *** Bluetooth version depends on module |
| USB |
Rear (12 ports) 1 × USB 20 Gbps (Type‑C) 3 × USB 10 Gbps (2 × Type‑A + 1 × Type‑C) 4 × USB 5 Gbps (4 × Type‑A) 4 × USB 2.0 (4 × Type‑A) Front (7 ports) 1 × USB 10 Gbps (Type‑C) 1 × USB 5 Gbps header (adds 2 ports) 2 × USB 2.0 headers (adds 4 ports) * Type‑C PD max 5 V/3 A |
| Audio |
ROG SupremeFX 7.1 Surround Sound CODEC ALC4080* - Impedance sense front/rear - Jack‑detection, multi‑streaming, MIC retasking - 120 dB SNR playback, 110 dB SNR recording - 32‑Bit/384 kHz front‑panel support Features: SupremeFX Shielding, Savitech SV3H712 AMP, rear optical S/PDIF, premium caps, audio cover * Requires chassis HD‑audio front panel for 7.1 output ** Rear LINE‑OUT does not support spatial audio |
| Back Panel I/O |
1 × USB 20 Gbps (Type‑C) 3 × USB 10 Gbps (2 × Type‑A + 1 × Type‑C) 4 × USB 5 Gbps (Type‑A) 4 × USB 2.0 (Type‑A) 1 × DisplayPort 1 × HDMI 2.1 1 × Wi‑Fi module 1 × Intel 2.5 Gb Ethernet 2 × Audio jacks (front/rear) 1 × Optical S/PDIF out 1 × BIOS FlashBack™ button 1 × Clear CMOS button |
| Internal Connectors |
Fans & Cooling 1 × 4‑pin CPU fan 1 × 4‑pin CPU OPT fan 1 × 4‑pin AIO pump 4 × 4‑pin chassis fans Power 1 × 24‑pin ATX main 2 × 8‑pin CPU +12 V Storage 4 × M.2 (Key M) slots 2 × SATA 6 Gb/s ports USB 1 × USB 10 Gbps (Type‑C) connector 1 × USB 5 Gbps header (adds 2 ports) 2 × USB 2.0 headers (adds 4 ports) Miscellaneous 3 × Addressable Gen 2 headers 1 × CPU‑over‑voltage jumper 1 × Front‑panel audio (F_AUDIO) 1 × Power button 1 × Front system panel (10‑1 pin) 1 × Thermal‑sensor header 1 × Thunderbolt (USB4) header |
| Special Features |
Extreme Engine Digi+ (5K black metallic caps) ASUS Q‑Design (Q‑Latch, Q‑Release, Q‑Slide, Q‑Release Slim, Q‑Antenna, Q‑Dashboard, Q‑DIMM, Q‑LED, Q‑Slot) ASUS Thermal Solution (M.2 heatsink backplate & heatsink) ASUS EZ DIY (BIOS FlashBack™ button, Clear CMOS button, pre‑mounted I/O shield, SafeSlot, SafeDIMM) Aura Sync (Addressable Gen 2 headers) |
| Software Features |
ROG exclusive: ROG CPU‑Z, Dolby Atmos ASUS: Armoury Crate, AIDA64 Extreme (60‑day trial), Aura Creator, Aura Sync, Fan Xpert 4, GameFirst, HWiNFO, Power Saving, DriverHub, GlideX, TurboV Core, Adobe Creative Cloud (trial), Norton 360 for Gamers (60‑day trial), WinRAR (40‑day trial) UEFI BIOS: ASUS CrashFree BIOS 3, EZ Flash 3, EZ Mode, MyHotkey |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE |
| Accessories |
2 × SATA 6 Gb/s cables ASUS Wi‑Fi Q‑Antenna, cable‑ties package, M.2 Q‑Latch & Q‑Slide packages, ROG key‑chain, stickers, 4 × M.2 rubbers Quick‑start guide |
| Operating System | Windows 11 |
| Form Factor | ATX (30.5 cm × 24.4 cm) |
Select Seller
From $352.45
Asus ROG STRIX B850-F Gaming WIFI AM5 ATX Motherboard (ROG STRIX B850-F GAMING WIFI)—
$352.45
