Klipsch DS-180CDT 8" In-Ceiling 200W Speaker with Pivoting Woofer/Tweeter (White)
HORN-LOADED PERFORMANCE
Using the same Tractrix® horn technology and design principles of our premium architectural and box speaker lines, the all-new Klipsch Designer series provides true Klipsch power and performance. With an 8” Polypropylene woofer and a 1” Silk Dome tweeter mated to a round Tractrix® horn, the DS-180CDT brings dynamic, powerful, detailed Klipsch sound to your distributed audio, home theater, or 2-channel system.
PATENT-PENDING SKYHOOK™ TOOL-FREE INSTALLATION SYSTEM
The exclusive installation system engages the dog legs automatically when the speaker is inserted into the cutout hole with a preset clamping force, eliminating the possibility of overtorquing. This fast, easy installation system reduces install time by up to 75%.
CONTROLLED DISPERSION TECHNOLOGY™
CDT technology allows for the tweeter and the woofer to be aimed up to 15°, helping to ensure on-axis frequency response at almost any listening position.
ALL-NEW, BEZEL-FREE GRILLE
A completely redesigned powder-coated steel grille eliminates the bezel for seamless, pristine integration into the living space.
FREQUENCY RANGE: 73Hz - 20kHz +/- 3dB
HIGH FREQUENCY DRIVER: 1" (2.54cm) Silk Dome Tweeter mated to a round Tractrix® Horn
LOW FREQUENCY DRIVER: 8" (20.32cm) Polypropylene Woofer
SENSITIVITY: 94 dB @ 2.83V / 1m
COVERAGE ANGLE: 100°
POWER HANDLING: 50W RMS / 200W RMS
IMPEDANCE: 8 Ohm Compatible
ENCLOSURE MATERIAL/TYPE: ABS / Infinite Baffle
FINISH: Black Baffle/Frame, White Paintable Grille
PRODUCT WEIGHT: 7.4 lbs (3.36kg)
INCLUDED IN BOX: Flat Paintable Grille
Speaker Diameter: 10.88" (27.64cm)
Cut Out Diameter: 9.57" (24.31cm)
Mounting Depth: 4.66" (11.84cm)
Includes:
1x Klipsch DS-180CDT 8" In-Ceiling Speaker w/ Pivoting Woofer & Tweeter
