TerraMaster D4 SSD 4 Bay NVMe M.2 SSD Enclosure (D4 SSD)

STORAGE

Disk Slot Number

4

Compatible Disk Types

PCIe NVMe M.2 2280 SSD

File System

NTFS, APFS, Mac OS, FAT32, EXT4, exFAT

Maximum Internal Raw Capacity

32 TB (8TB SSD * 4)

RAIDs Supported

SINGLE DISK

USB

USB4 40Gbps

READING/WRITING SPEED (MAX.)

Reading Speed (max.)

3257 MB/s (Samsung 990 Pro 4TB*4_RAID0); 1600MB/s (Samsung 990 Pro 4TB*1)

Writing Speed (max.)

3192 MB/s (Samsung 990 Pro 4TB*4_RAID0); 1500MB/s (Samsung 990 Pro 4TB*1)

APPEARANCE

Size (H*W*D)

138 x 60 x 140 mm

Packaging Size (H*W*D)

185 x 172 x 152 mm

Weight

Net weight: 392g, Gross Weight: 891g

OTHERS

System fan

50 x 50 x 10mm 2PCS

Fan mode

Smart

Noise Level

19.0 dB(A) (Using M.2 SSDs in standby mode; Test environment noise: 17.3dB(A); Test distance: 1m)

POWER SUPPLY

Power Supply

24 W

AC Input Voltage

100V to 240V AC

Current Frequency

50/60 Hz, Single Phase

Power Consumption

15.0 W (Fully loaded Seagate 2TB M.2 SSDs in read/write state)

6.0 W (Fully loaded Seagate 2TB M.2 SSDs in hibernation)

ENVIRONMENT TEMPERATURE

Working Temperature

0 °C ~ 40 °C (32 °F ~ 104 °F)

Storage Temperature

-20 °C ~ 60 °C (-5 °F ~ 140 °F)

Relative Humidity

5% ~ 95% RH

Supported OS

Mac OS、Windows 11(24H2 or later version)

Certificate

CE, FCC, CCC, KC

Environment

RoHS compliance

PACKAGE CONTENTS

Package Contents

Host unit (x1)

USB4 Cable C to C 0.8m (x1)

Quick Installation Guide (x1)

Power adapter (x1)

Screws (several)

Limited Warranty Note (x1)
